Excavator digunakan bantalan semua jenis fitur bantalan excavator:
1) Excavator bearing khusus ball bearing sudut digunakan untuk aplikasi mesin excavator.
2) bantalan kontak sudut Excavator memiliki sudut kontak besar (40 derajat), sehingga dapat melakukan beban aksial besar.
3) Bantalan excavator dapat membawa kapasitas beban yang lebih berat daripada bantalan ukuran yang sama karena memiliki
lebih banyak bola di dalam. Ini banyak digunakan untuk semua excavator impor.
4) Akurasi tinggi, kebisingan rendah, umur panjang dan kekakuan bantalan ini banyak digunakan dalam excavator.
5) Aplikasi: EXCAVATOR KOBELCO, EXCAVATOR, EXCAVATOR CATERPILLAR, EXCAVATOR KATO, EXCAVATOR HITACHI, EXCAVATOR DAEWOO, EXCAVATOR HYUNDAI, EXCAVATOR HYUNDAI, EXCAVATOR VOLVO, DLL.
Bantalan 240BA3251 gambar dan data teknis:
| Bantalan bola kontak sudut 240BA3251 | |||||
| Nomor bantalan: 240BA3251 | |||||
| Ukuran (mm): 240x320x38 | |||||
| Merek: NTN | |||||
| Diameter Bor (mm): 240 | |||||
| Diameter Luar (mm): 320 | |||||
| Lebar (mm): 38 | |||||
| Dimensi dan spesifikasi bantalan dalam katalog NTN: | |||||
| d - 240 mm | |||||
| D - 320 mm | |||||
| T - 38 mm | |||||
| Tag: NTN, 240 * 320 * 38 |
Produk Menunjukkan:
| Bantalan NO. | d | D | H | W |
| AC5836 | 289 | 355 | 34 | 4.6 |
| AC5033 | 250 | 330 | 37 | 6 |
| AC463240 | 230 | 320 | 40 | 7.2 |
| AC4629 | 230 | 290 | 27 | 3.2 |
| AC4531 | 225 | 315 | 36 | 5 |
| AC423040 | 210 | 300 | 40 | 5.4 |
| AC4630 | 230 | 300 | 35 | 5.4 |
| AC6037 | 300 | 370 | 33 | 5.8 |
| AC4631 | 230 | 310 | 39 | 5.4 |
| AC523438-1 | 260 | 340 | 38 | 6 |
| BA195-3A | 195 | 280 | 36.5 | 6.2 |
| BA152-2036 | 150 | 203 | 26 | 1.5 |
| BA222-1WSA | 222 | 273 | 26 | 2.3 |
| BA220-6WSA | 220 | 276 | 26 | 2.7 |
| BA240-3WSA | 240 | 310 | 33.5 | 4.5 |
| BA230-7WSA | 230 | 300 | 35 | 5.4 |
| BA180-4WSA | 180 | 250 | 33 | 3.2 |
| BA280-2WSA | 280 | 370 | 40 | 6 |
| BA300-4WSA | 300 | 395 | 50 | 11.5 |
| BA205-1 | 202 | 295 | 40 | 7 |
| BA180-2256 | 180 | 2250 | 21.5 | 1.5 |
| BA184-2251 | 184 | 226 | 21.5 | 1.6 |
| BA290-3A | 290 | 280 | 40 | 9.4 |
| BA250-4A | 250 | 330 | 38 | 6.2 |
| BA246-2A | 246 | 313 | 32 | 4.3 |
| BA289-1 | 289 | 355 | 33 | 4.6 |
| BA210-10 | 300 | 280 | 38 | 5.5 |
| BA300-5 | 300 | 380 | 40 | 9.5 |
| BA230-2 | 230 | 320 | 40 | 5.4 |
| BA260-3 | 260 | 340 | 38 | 7.2 |
| BA260-4 | 260 | 340 | 38 | 7.2 |
| BA-220-1 | 220 | 280 | 28 | 3 |
| BA270-3 | 270 | 350 | 40 | 6.6 |
| BA16519 | 165 | 203 | 19 | 1.5 |
| 120BA16 | 120 | 165 | 22 | 1.1 |
| 260BA355-2 | 260 | 355 | 44 | 6 |
| 180BN19W | 180 | 250 | 33 | 3.5 |
| MC6034 | 600 | 340 | 18 | 3.2 |
| BA168-1 | 168 | 205 | 20 | |
| BA200-7B | 200 | 250 | 24 | 2.1 |
| SF2812PX1 | 140 | 175 | 17.5 | 0,6 |
| SF3227VPX1 | 160 | 200 | 10 | 1.2 |
| SF3607 | 180 | 225 | 24 | 1.2 |
| SF4826VPX1 | 240 | 310 | 33 | 5.1 |
| SF4852VPX1 | 240 | 310 | 33 | 5 |
| SF4820PX1 | 240 | 310 | 34 | 5.2 |
| SF4815VPX1 | 240 | 310 | 34 | 5 |
| SF4831VPX1 | 240 | 310 | 33.4 | 5.2 |
| SF4007VPX1 | 200 | 250 | 24 | 1.7 |
| SF4019VPX1 | 200 | 260 | 30 | 3.5 |
| SF3235VPX1 | 260 | 330 | 35 | 5.2 |
| SF4444VPX1 | 220 | 295 | 32 | 4.5 |
| SF4454VPX1 | 220 | 295 | 33 | 4.8 |
| SF4411VPX1 | 220 | 290 | 32.5 | 5.5 |
| SF6015PX1 | 300 | 372 | 36 | 6 |
| 200BA27V | 200 | 270 | 33 | |
| 210BA29V | 210 | 295 | 35 | |
| 240BA3251 | 240 | 320 | 38 | 5 |
| BD130-1WSA | 130 | 166 | 34 | 1.4 |
